Mast Chain

Forklift Mast Chain - Leaf Chains have several applications and are regulated by ANSI. They are used for low-speed pulling, for tension linkage and lift truck masts, and as balancers between counterweight and head in several machine tools. Leaf chains are occasionally likewise referred to as Balance Chains.

Features and Construction

Leaf chains are actually steel chains using a simple pin construction and link plate. The chain number refers to the pitch and the lacing of the links. The chains have particular features like for example high tensile strength per section area, which allows the design of smaller devices. There are B- and A+ type chains in this particular series and both the BL6 and AL6 Series include the same pitch as RS60. Finally, these chains cannot be powered utilizing sprockets.

Handling and Selection

In roller chains, the link plates have a higher fatigue resistance because of the compressive tension of press fits, yet the leaf chain only contains two outer press fit plates. On the leaf chain, the most acceptable tension is low and the tensile strength is high. While handling leaf chains it is essential to confer with the manufacturer's handbook in order to guarantee the safety factor is outlined and utilize safety guards at all times. It is a great idea to carry out utmost care and use extra safety guards in functions where the consequences of chain failure are serious.

Using much more plates in the lacing leads to the higher tensile strength. As this does not enhance the most allowable tension directly, the number of plates utilized can be limited. The chains need regular lubrication because the pins link directly on the plates, generating a really high bearing pressure. Utilizing a SAE 30 or 40 machine oil is frequently advised for the majority of applications. If the chain is cycled more than one thousand times day after day or if the chain speed is more than 30m for each minute, it will wear very fast, even with constant lubrication. Hence, in either of these conditions the use of RS Roller Chains would be more suitable.

The AL-type of chains must just be utilized under particular situations like for instance if wear is really not a big concern, when there are no shock loads, the number of cycles does not go beyond 100 a day. The BL-type would be better suited under various situations.

The stress load in components will become higher if a chain with a lower safety factor is selected. If the chain is also used among corrosive conditions, it could easily fatigue and break really quick. Performing regular maintenance is essential when operating under these types of situations.

The outer link or inner link kind of end link on the chain would determine the shape of the clevis. Clevis connectors or likewise known as Clevis pins are constructed by manufacturers, but the user normally provides the clevis. A wrongly constructed clevis can lessen the working life of the chain. The strands should be finished to length by the producer. Refer to the ANSI standard or contact the producer.
